Heavy-Duty Lifting Solutions for Commercial Trucks & Cold-Chain Fleets

Kingtec Tail Lifts are engineered to provide safe, efficient, and reliable loading/unloading for commercial trucks, refrigerated vehicles, and logistics fleets. Built with high-strength steel/alloy platforms, precision hydraulic systems, and advanced control units, these lifts improve productivity and reduce manual handling risks across all industries.

Key Features

  • Wide capacity range from 500 kg to 3000 kg, covering vans to heavy trucks

  • Robust hydraulic system with single/double-acting cylinders for stable lifting

  • Steel / Alloy platform options for weight optimization

  • Advanced control unit with control box + wired liner-control for operator safety

  • Smooth lift & tilt mechanism for precise loading operations

  • Compatible with multiple truck chassis configurations

  • Proven durability using Sweden-technology Haldex valve (mid & high-capacity models)

Applications / Use Cases

Kingtec tail lifts are ideal for:

  • Cold-chain distribution trucks

  • Refrigerated & insulated bodies

  • Supermarket delivery vehicles

  • Courier & parcel logistics

  • Heavy-duty industrial cargo fleets

  • Warehousing & palletized goods movement

  • Multi-temperature trucks with frequent loading/unloading

Performance Benefits

  • Faster loading/unloading, improving fleet turnaround time

  • Reduced manual labor, lowering injury risk

  • Stable lifting under full load, thanks to balanced cylinder design

  • Durable construction suitable for GCC climate and heavy usage

  • Easy to control with ergonomic liner-control remote

  • Long service life with proven Haldex hydraulic technology in mid/high-capacity units

Dimensions & Weights (Category Overview)

  • Platform widths: 1200 mm to 1800 mm

  • Platform lengths: 1550 mm to 2336 mm

  • Gross weight range: 240 kg to 680 kg (model dependent)

  • Lifting heights: 900 mm to 1550 mm

Each model is designed to suit different truck classes and body dimensions.

Why Choose Kingtec Tail Lifts?

  • Engineered for high reliability & safety

  • Suitable for 16+ global truck brands

  • Integrates perfectly with refrigerated body solutions

  • Backed by Kingtec Middle East’s service network & spare parts support

  • Proven durability in Middle East climate & road conditions

Download Brochure

Get full model-by-model drawings, schematics & installation specs.
👉 Download the Kingtec Tail Lift Catalogue (PDF)

Category:

Description

Model Load Capacity Lifting Height Board Size (mm) Cylinders Powerpack Control Unit Gross Weight Ideal For
YZ-0.5-900 500 kg 900 mm 1550 × 1200 (Steel/Alloy) 2× lifting (single acting), 1–2× tilting (double acting) 12V / 1.6KW / 0.85cc / 4L Control box + liner control 240–280 kg Vans, small trucks
YZ-8-1 750 kg 900 mm 1800 × 1400 2× lifting (single acting), 2× tilting (double acting) 12V / 1.6KW / 0.85cc / 4L Control box + liner control 260–320 kg Small–mid trucks
YZ-10-120 1000 kg 1200 mm 1800×1700 / 2000×1700 2× lifting (single acting), 2× tilting (single acting) Sweden tech Haldex valve Control box + liner control 420–490 kg Medium trucks
YZ-15-135 1500 kg 1350 mm 2200 × 1800 2× lifting (single acting), 2× tilting (single acting), 1× balance Sweden tech Haldex valve Control box + liner control 450–520 kg Refrigerated trucks
YZ-20-150 2000 kg 1500 mm 2300 × 1800 2× lifting (single acting), 2× tilting (single acting), 1× balance Sweden tech Haldex valve Control box + liner control 460–550 kg Heavy trucks
YZ-25-155 2500 kg 1550 mm 2300 × 1800 2× lifting (single acting), 2× tilting (single acting), 1× balance Sweden tech Haldex valve Control box + liner control 600 kg Heavy-duty cargo
YZ-30-155 3000 kg 1550 mm 2300 × 1800 2× lifting (single acting), 2× tilting (single acting), 1× balance Sweden tech Haldex valve Control box + liner control 640 kg Industrial grade / high load
YZ-SZ-15-2 1500 kg 1450 mm 2330 × 1610 (Alloy, roll stop) 2× lifting, 2× tilting Mechanical auto-tilt Made in China 680 kg Supermarket & palletized cargo
YZ-SZ-20-2 2000 kg 1450 mm 2330 × 1610 (Alloy, roll stop) 2× lifting, 2× tilting Mechanical auto-tilt Made in China 680 kg Heavy pallets, warehouse fleets
YZ-LZ-15-2 1500 kg 1450 mm 2336 × 1668 (Alloy, roll stop) 2× lifting, 2× tilting Mechanical auto-tilt Made in China 600 kg Temperature-controlled logistics
YZ-LZ-20-2 2000 kg 1450 mm 2336 × 1668 (Alloy, roll stop) 2× lifting, 2× tilting Mechanical auto-tilt Made in China 630 kg Food & pharma logistics
