Kingtec K360
The Kingtec K360 series is designed for fresh refrigeration in 5-10m³ freezer trucks and vans. It features a dual-compressor system—one powered by the vehicle’s engine for on-road cooling and another electric standby motor for stationary use—ensuring efficient temperature control for perishable goods.
Key Features:
- Dual-Compressor System: One compressor runs on the vehicle’s engine, while an electric standby motor powers the second, offering flexibility for on-road and stationary cooling.
- High Cooling Capacity: Delivers up to 2510 watts (8560 BTU/hr) at 0°C (32°F) on the road, maintaining optimal temperatures for fresh goods.
- Eco-Friendly Refrigerant: Uses chlorine-zero R134a refrigerant (1.3kg), ensuring environmentally responsible operation.
- Compact and Lightweight Design: Condenser and evaporator assemblies weigh only 25kg each, with dimensions optimized for easy installation (870 x 230 x 505 mm for the condenser).
- Powerful Airflow: EVK300C evaporator provides 1380m³/h (810 cu.ft/min) airflow, ensuring uniform cooling throughout the cargo space.
Click to Download Product Brochure
Description
System Components
Product Specifications:
| Category | Details |
|---|---|
| Application | 15-40m³ medium refrigerator trucks and vans |
| Refrigeration Capacity | YQZ500 (R404A): 4920 Watts / 16728 BTU/hr at 0°C (32°F); 2338 Watts / 9649 BTU/hr at -20°C (-4°F) YQZ500 (R134A): 4230 Watts / 16082 BTU/hr at 2°C (35°F); 2762 Watts / 9331 BTU/hr at -18°C (0°F) |
| Air Return on the Road | YQZ500 (R404A): 3640 Watts / 12400 BTU/hr at 0°C (32°F); 1950 Watts / 6600 BTU/hr at -20°C (-4°F) YQZ500 (R134A): 3700 Watts / 12600 BTU/hr at 2°C (35°F); 1680 Watts / 5700 BTU/hr at -18°C (0°F) |
| Refrigerant | YQZ500 (R404A): HFC R404A, 1.5kg YQZ500 (R134A): HFC R134A, 1.6kg |
| Road Compressor | QP16 (163cc); Max recommend RPM: 3000rpm |
| Airflow Volume | Evaporator: 1650m³/h (970 cfm/min) |
| Defrost | Automatic hot gas defrost |
| Weight | Integrated condenser and evaporator: 98kg |
| Dimensions (mm/in) | Length: 1600mm (63.0″) Width: 814mm (32.0″) Height: 145mm (5.7″) Evaporator Height: 470mm (18.5″) Condenser Height: 480mm (18.9″) |
| Controller | AE Controller |
