Kingtec FR-500
The KINGTEC FR-600 series unit is engineered for fresh and frozen applications in 15–25m³ small refrigerated trucks. It’s powered by the vehicle engine, with an optional electric standby system. The unit is designed to be safe, energy-efficient, and easy to install.
Key Features:
-
Designed for both fresh and frozen transport (up to 25m³).
-
Optional fully enclosed electric standby compressor for energy efficiency.
-
High-capacity airflow: EVK500 delivers 2400 m³/h.
-
Hot gas defrost system for reliable operation in all climates.
-
Dual DC power compatibility (12V/24V) with oil-return system for compressor safety.
Click to Download Product Brochure
Description
System Components
| Specification | Details |
|---|---|
| Refrigerant (Chlorine-Free) | HFC R404A – 2.3 kg |
| Compressor Type | Swash plate, 6-cylinder |
| Engine Compressor Model | QP21 (215 cc) |
| Max Engine RPM | 3000 RPM |
| Airflow Volume | EVK500: 2400 m³/h (1410 cu ft/min) |
| Defrost System | Hot gas defrost |
| Voltage Options | DC12V or DC24V |
| Current Consumption | 12V: 50A, 24V: 25A |
| Weights | |
| – Condenser Assembly | 35 kg / 77 lbs |
| – EVK500 Evaporator Assembly | 35 kg / 77 lbs |
| – Electrical Stand-by Assembly | 25 kg / 55 lbs |
| Cooling Capacity (ATP Standard) | 0°C: 5400 W / 18414 BTU/hr -20°C: 3300 W / 11253 BTU/hr |
| Cooling Capacity (US Standard) | 2°C: 5000 W / 17050 BTU/hr -18°C: 2800 W / 9548 BTU/hr |
